Material of Construction: 6mm thick asbestos lined FRP Bispheonl "A" fumerate resin rein forced with veneer ply sheet 12 mm thick. External laminated with melamine sheet. Door: Single, automatic, concealed type balanced with counter weights, sash weights, wire rope and others. Motor: 1 H.P. 1440 RPM, three phase motor Ducting: 200MM dia thick, rigid PVC pipe of height 8' will be provided with suitable rain hood. Impeller: Dynamically balanced FRP impeller. Buffed by 3 mm thick FRP sheet. Exhaust blower: Centrifugal dulvin type, in-built Casting: 6 mm thick FRP Bisphenol "A" fumerate resin. Temperature: Max 120'C pressure 2" swg Suction: 1000/1200 cfm per minute. Balancing: By suitable equipment upto 3000 RPM Bottom Arrangement: 3' Height table made out of 19mm black board with sliding door, open door and one number horizontal partition internally coated with epoxy paint. Flooring: Working surface shall be floored with spartek tiles with acid resistant cement joints. Electrical Arrangement: 2 Nos of 3 pin 15/5 amp socket, with control switch and bush type starter will be provided. Overall Dimension Approx.: 8 X 5 X 2.5 Feet Power Supply: 230 Volts 50 Hz Ac Main 3 Wire System.
